Features Body – Polypropylene for resistance to acids and other chemicals. Maximum working pressure 785kPa Minimum working pressure on pressurized systems must be 98kPa. When using on bypass pressure differential between the inlet and outlet must be at least 70kPa. Venturi should always be installed on a level plain. Suction Line Kits Without Injectors Model Number Compatible Injectors Parts Included Weight (lbs) Weight (kg) K-184 0.5″ (15mm) and 0.75″ injectors (10′ coiled) and (2″ piece) Clear Vinyl Tubing (1) MV-25A Metering Valve (2) CLAMPS#23 (1) S-25HB Strainer 0.45 lbs 0.20 kg K-183 1″ and 1.5″ injectors (10′ coiled) and (2″ piece) Clear Vinyl Tubing (1) MV5-PP Metering Valve (4) CLAMPS#44 (1) S-50HB Strainer (2) TA-550F Tubing Adapters 1.60 lbs 0.73 kg KR-183 1″ and 1.5″ injectors (6′ coiled) and (2″ piece) Clear Vinyl Tubing (1) 0.5″ PVC Ball Valve (4) CLAMPS#44 (1) S-50HB Strainer (2) TA-550 Tubing Adapters 1.05 lbs 0.48 kg K-282 2″ injectors (1) 1″ PVC Ball Valve (2) #16 Stainless Steel Clamps (1) S-87 Strainer (1) C-86 CLEAR Check Valve Misc. PVC Fittings 5.15 lbs 2.34 kg
