Senninger Wobbler Sprinklers

Features: Provides extremely uniform coverage over large diameters Only one moving part, which translates to longer product life Available in standard and low angle models Overview Wobblers produce droplets resistant to wind drift and evaporation and distribute them in a gentle, rain-like pattern. 20mm Male BSP thread The minimum recommended riser height is 0.46 m. Standard Wobbler Sprinkler: Nozzle Sizes: 2.38mm - 5.56mm Flow Range: 177 - 1735 L/hr Pressure Range: 0.69 - 2.07 BAR (10 - 30 PSI) Diameters of Coverage: 10.4m - 16.0m (0.46m in height) Low Angle Wobbler Sprinkler: Nozzle Sizes: 2.38mm - 5.56mm Flow Range: 177 - 1735 L/hr Pressure Range: 0.69 - 2.07 BAR (10 - 30 PSI) Diameters of Coverage: 8.8m - 14.6m (0.91m in height) Nozzle Specifications - Standard and Low Angle Nozzle & Flow Pressure - Bar 0.69 1.04 1.38 1.72 2.07 #6 Nozzle - Gold (2.38 mm) Flow (L/hr) 177 216 250 279 307 SA Diameter at 0.46 m ht (m) 10.4 11.9 12.7 13.3 13.4 LA Diameter at 0.46 m ht (m) 8.8 10.5 11.6 12.4 12.5 #7 Nozzle - Lime (2.78 mm) Flow (L/hr) 241 295 341 382 418 SA Diameter at 0.46 m ht (m) 11.1 12.7 13.3 13.7 13.9 LA Diameter at 0.46 m ht (m) 9.6 11.3 12.2 12.7 12.8 #8 Nozzle - Lavender (3.18 mm) Flow (L/hr) 318 388 450 502 550 SA Diameter at 0.46 m ht (m) 11.7 13.3 13.7 14.2 14.3 LA Diameter at 0.46 m ht (m) 10.4 11.9 12.7 13 13.1 #9 Nozzle - Grey (3.57 mm) Flow (L/hr) 409 500 577 645 706 SA Diameter at 0.46 m ht (m) 12.4 13.9 14.2 14.5 14.6 LA Diameter at 0.46 m ht (m) 10.8 12.4 13 13.3 13.4 #10 Nozzle - Turquoise (3.97 mm) Flow (L/hr) 504 618 713 797 874 SA Diameter at 0.46 m ht (m) 12.8 14.3 14.6 14.8 14.9 LA Diameter at 0.46 m ht (m) 11 12.5 13.1 13.4 13.6 #11 Nozzle - Yellow (4.37 mm) Flow (L/hr) 611 749 865 968 1061 SA Diameter at 0.46 m ht (m) 13.1 14.6 14.9 15.1 15.3 LA Diameter at 0.46 m ht (m) 11.1 12.8 13.3 13.6 13.7 #12 Nozzle - Red (4.76 mm) Flow (L/hr) 734 899 1038 1161 1272 SA Diameter at 0.46 m ht (m) 13.4 14.9 15.3 15.4 15.6 LA Diameter at 0.46 m ht (m) 11.3 13 13.4 13.7 13.9 #13 Nozzle - White (5.16 mm) Flow (L/hr) 863 1056 1222 1365 1497 SA Diameter at 0.46 m ht (m) 13.6 15.1 15.4 15.5 15.7 LA Diameter at 0.46 m ht (m) 11.4 13.1 13.6 13.9 14 #14 Nozzle - Blue (5.56 mm) Flow (L/hr) 999 1224 1415 1583 1735 SA Diameter at 0.46 m ht (m) 13.7 15.3 15.6 15.7 15.9 LA Diameter at 0.46 m ht (m) 11.6 13.3 13.7 14 14.2
