Senninger Xcel Wobbler Sprinklers

Features: Provides extremely uniform coverage over large diameters Only one moving part, which translates to longer product life Available in High and Mid angle models 20mm Male threaded connection Overview Wobblers produce droplets resistant to wind-drift and evaporation, and distribute them in a gentle, rain-like pattern. Minimum recommended riser height is 0.46 m. High Angle Xcel Wobbler Sprinkler: Nozzle Sizes: 2.38mm - 5.56mm Flow Range: 177 - 1583 L/hr Pressure Range: 0.69 - 1.72 BAR (10 - 25 PSI) Diameters of Coverage: 11.1m - 16.9m (0.46m in height) Mid Angle Xcel Wobbler Sprinkler: Nozzle Sizes: 2.38mm - 5.56mm Flow Range: 177 - 1583 L/hr Pressure Range: 0.69 - 1.72 BAR (10 - 25 PSI) Diameters of Coverage: 9.8m - 14.6m (0.91m in height) Nozzle Selection Nozzle & Flow Specifications Pressure - BAR 0.69 1.04 1.38 1.72 #6 Nozzle - Gold (2.38 mm) Flow (L/hr) 177 216 250 279 High Angle Diameter Angle (Diameter at 0.46 m ht (m)) 11.1 12.5 13.7 14 Medium Angle Diameter Angle (Diameter at 0.46 m ht (m)) 9.8 10.7 11.7 12.5 #7 Nozzle - Lime (2.78 mm) Flow (L/hr) 241 295 341 382 High Angle Diameter Angle (Diameter at 0.46 m ht (m)) 12.2 14.2 14.3 15.4 Medium Angle Diameter Angle (Diameter at 0.46 m ht (m)) 10.1 11.1 12.3 12.5 #8 Nozzle - Lavender (3.18 mm) Flow (L/hr) 318 388 450 502 High Angle Diameter Angle (Diameter at 0.46 m ht (m)) 12.8 14.2 14.3 15.7 Medium Angle Diameter Angle (Diameter at 0.46 m ht (m)) 10.4 11.7 12.5 13 #9 Nozzle - Grey (3.57 mm) Flow (L/hr) 409 500 577 645 High Angle Diameter Angle (Diameter at 0.46 m ht (m)) 13.4 14.3 15.4 16 Medium Angle Diameter Angle (Diameter at 0.46 m ht (m)) 10.5 12.4 12.8 13.1 #10 Nozzle - Turquoise (3.97 mm) Flow (L/hr) 504 618 713 797 High Angle Diameter Angle (Diameter at 0.46 m ht (m)) 13.6 14.9 15.4 16.3 Medium Angle Diameter Angle (Diameter at 0.46 m ht (m)) 11 12.5 13 13.4 #11 Nozzle - Yellow (4.37 mm) Flow (L/hr) 611 749 865 968 High Angle Diameter Angle (Diameter at 0.46 m ht (m)) 13.6 15.4 15.7 16.5 Medium Angle Diameter Angle (Diameter at 0.46 m ht (m)) 11 12.7 13.1 13.4 #12 Nozzle - Red (4.76 mm) Flow (L/hr) 734 899 1038 1161 High Angle Diameter Angle (Diameter at 0.46 m ht (m)) 14 15.4 15.9 16.6 Medium Angle Diameter Angle (Diameter at 0.46 m ht (m)) 11.1 12.2 13.6 13.6 #13 Nozzle - White (5.16 mm) Flow (L/hr) 863 1056 1222 1365 High Angle Diameter Angle (Diameter at 0.46 m ht (m)) 14.2 15.6 16 16.9 Medium Angle Diameter Angle (Diameter at 0.46 m ht (m)) 11.1 12.7 13.6 13.7 #14 Nozzle - Blue (5.56 mm) Flow (L/hr) 999 1224 1415 1583 High Angle Diameter Angle (Diameter at 0.46 m ht (m)) 14.3 15.6 16.2 16.9 Medium Angle Diameter Angle (Diameter at 0.46 m ht (m)) 11.3 13 13.7 14.2
